2BE series liquid ring vacuum pumps are usually used to suction the gas without solid particle, undissolved and noncorrosive gas to generate vacuum and pressure in the closed container. By changing the pump material, they can also be used to suction corrosive gas or use corrosive liquid as operating liquid. They are widely used in paper-making, chemical, petrification, light industry, pharmacy, instruments, metallurgy, construction, electronical appliance, coal-cleaning, mineral concentration, fertilizer, etc.
2BE liquid ring vacuum pump is single stage pump with simple structure. It’s easy maintenance, reliable,efficient and energy-saving operation . They can run under tough working conditions with large drainage discharge and changing load impact. 2BE vacuum pumps adopt unique polytetrafluoroethylene valve plates (former liquid ring pumps use ball valves) for their exhausting systems. Each valve plate is covered on vents in outer side of a port plate and fixed by a stainless steel baffle at its other side. Curvature of the valve plate changes with inlet pressure so that pumping medium can be discharged when it reaches the inlet pressure. Such structure avoids over-compression in a vacuum system and automatically adjusts exhausting area to lower power consumption, thus a best operating efficiency can be obtained.
The key parts of 2BE series liquid ring vacuum pumps, such as distribution plate, impeller and pump shaft are simplified in structure with performance improved, thus it’s very energy-saving.
Dynamic balance problem is radically solved because during impeller welding, blades are formed by one-step stamping with rational molded lines and all wheel hubs are processed. The impeller and pump shaft combined by shrinkage interference fit perform reliably and smoothly. Blades of the impeller will obtain good ductility after the impeller is welded and processed by overall heat treatment, thus impact resistance and flexure resistance of the blades are fundamentally guaranteed the application under tough working condition with changing load impact.
The 2BE pumps are equiped with gas-water separators itself, Many position has the exhausting hole. It is very easy to connect with the vacuum system. What’s more, the pump cover with inspeciton window which can regulate the gland packing of the shaft to adjust the impeller and distributoring plate. All vacuum pumps will be subjected to strict inspections and tests in our testing center so as to guarantee their excellent, reliable and long lasting performances.
| Model | Speed
(Driving mode) [r/min] |
Shaft power
[kW] |
Motor power
[kW] |
Ultimate vacuum
[mbar] |
Max. capacity
[m3/h] [m3/min] |
||
| 2BE1-101 | 1450
1300 1750 |
(direct)
(V-belt) (V-belt) |
4.2
3.5 5.8 |
4P-5.5
4P-5.5 4P-7.5 |
33 | 168
152 202 |
3.4
2.5 2.8 |
| 2BE1-102 | 1450
1750 |
(direct)
(V-belt) |
6.0
8.0 |
4P-7.5
4P-11 |
33 | 246
290 |
4.1
4.8 |
| 2BE1-103 | 1450
1750 |
(direct)
(V-belt) |
8.2
11.1 |
4P-11
4P-15 |
33 | 340
412 |
5.7
6.9 |
| 2BE1-151 | 1450
1625 1750 |
(direct)
(V-belt) (V-belt) |
10.8
13.2 14.8 |
4P-15
4P-18.5 4P-22 |
33 | 390
440 465 |
6.5
7.3 7.8 |
|
2BE1-152 |
1450
1625 1750 |
(direct)
(V-belt) (V-belt) |
12.5
15.0 17.2 |
4P-15
4P-18.5 4P-22 |
33 |
450
510 535 |
7.5
8.5 8.9 |
| 2BE1-153 | 1450
1100 1300 1620 1750 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) |
16.3
10.6 13.4 19.6 22.3 |
4P-18.5
4P-15 4P-18.5 4P-22 4P-30 |
33 | 600
445 535 648 700 |
10.0
7.4 8.9 10.8 11.7 |
| 2BE1-202 | 980
790 880 1100 1170 1300 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) (V-belt) |
18.2
13.4 16.3 23.8 25.7 30 |
6P-22
4P-18.5 4P-18.5 4P-30 4P-30 4P-37 |
33 | 750
590 670 860 888 950 |
12.5
9.8 11.2 14.3 14.8 15.8 |
| 2BE1-203 | 980
790 880 1100 1170 1300 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) (V-belt) |
29.5
21.2 24.8 34 38 42 |
6P-37
4P-30 4P-30 4P-45 4P-45 4P-55 |
33 | 1080
870 980 1210 1320 1390 |
18
14.5 16.3 20.2 22.0 23.2 |
| 2BE1-204 | 980
790 880 1100 |
(direct)
(V-belt) (V-belt) (V-belt) |
31.8
22.5 26.7 41.6 |
6P-37
4P-30 4P-37 4P-55 |
33 | 1230
996 1098 1452 |
20.5
16.5 18.3 24.2 |
| 2BE1-252 | 740
565 660 820 885 938 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) (V-belt) |
38
23.7 31.8 45 54 60 |
8P-45
4P-30 4P-37 4P-55 4P-75 4P-75 |
33 |
1700
1200 1500 1770 2000 2100 |
28.3
20.0 25.0 29.5 33.3 35.0 |
| 2BE1-253 | 740
565 660 792 820 880 940 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) (V-belt) (V-belt) |
50.8
37.2 45 60 68 75.1 88 |
8P-75
4P-45 4P-55 4P-75 4P-75 4P-90 4P-110 |
33 |
2340
1690 2100 2560 2640 2780 3050 |
39
28.2 35 42.7 44 46.3 50.8 |
| 2BE1-303 | 740
590 466 530 583 660 |
(direct)
(direct) (V-belt) (V-belt) (V-belt) (V-belt) |
98
65.5 48 58 64 79.8 |
8P-110
10P-75 4P-55 4P-75 4P-75 4P-90 |
33 | 3840
3200 2520 2820 3100 3550 |
64
53.3 42 47 51.7 59.2 |
| 2BE1-305 | 740
590 490 530 583 660 |
(direct)
(direct) (V-belt) (V-belt) (V-belt) (V-belt) |
108
70 55 61 68 90 |
8P-132
10P-90 4P-75 4P-75 4P-90 4P-110 |
33 | 4520
3750 3150 3380 3700 4090 |
75.3
62.5 52.5 56.4 61.2 68.1 |
| 2BE1-353 | 590
390 425 464 530 560 620 660 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) (V-belt) (V-belt) (V-belt) |
121
63 72 85 95 110 133 152 |
10P-160
4P-75 4P-90 4P-110 4P-110 4P-132 4P-160 4P-185 |
33 | 5300
3580 3700 4100 4620 5000 5500 5850 |
88.3
59.7 61.7 68.3 77.0 83.3 91.7 97.5 |
| 2BE1-355 | 590
390 430 464 523 660 |
(direct)
(V-belt) (V-belt) (V-belt) (V-belt) (V-belt) |
136
75 86 90 113 167 |
10P-160
4P-90 4P-110 4P-110 4P-132 4P-185 |
33 | 5700
4180 4260 4850 5230 6510 |
95
69.7 71 80.8 87.1 108 |
| 2BE1-403 | 330
372 420 472 530 |
(V-belt)
(V-belt) (V-belt) (V-belt) (V-belt) |
98
110 131 160 213 |
4P-132
4P-132 4P-160 4P-200 4P-250 |
33 | 4860
5400 6470 7380 8100 |
81
90 107.8 123.0 135.0 |
| 2BE1-405 | 330
372 420 472 530 |
(V-belt)
(V-belt) (V-belt) (V-belt) (V-belt) |
100
118 140 170 206 |
4P-132
4P-160 4P-185 4P-200 4P-250 |
6000
6700 7500 8350 9450 |
100.0
111.7 125.0 139.2 157.5 |
|
| 2BE1-503 | 266
298 330 372 420 472 |
(V-belt)
(V-belt) (gearbox) (gearbox) (gearbox) (gearbox) |
126
143 167 190 240 303 |
6P-132
6P-160 4P-185 4P-220 4P-280 4P-355 |
33 | 6780
7680 8310 9294 10458 11652 |
113
128 138.5 154.9 174.3 194.2 |
| 2BE1-505 | 266
298 330 372 420 |
(V-belt)
(gearbox) (gearbox) (gearbox) (gearbox) |
130
150 172 205 250 |
6P-160
4P-185 4P-220 4P-250 4P-280 |
160 | 7700
8800 9750 10750 11820 |
128.3
146.7 162.5 179.2 197 |
| 2BE1-603 | 236
266 298 330 372 398 |
(gearbox)
(gearbox) (gearbox) (gearbox) (gearbox) (gearbox) |
180
210 242 280 360 420 |
6P-220
4P-250 4P-280 4P-315 4P-400 4P-450 |
33 | 9720
10980 12300 13800 15480 16380 |
162
183 205 230 258 273 |
| 2BE1-605 | 236
266 298 330 372 398 |
(gearbox)
(gearbox) (gearbox) (gearbox) (gearbox) (gearbox) |
188
220 262 310 380 428 |
6P-220
4P-280 4P-315 4P-355 4P-450 4P-500 |
160 | 11500
13000 14900 15700 17250 18250 |
191.7
216.7 248.3 261.7 287.5 304.2 |
| 2BE1-703 | 210
236 266 298 330 |
(gearbox)
(gearbox) (gearbox) (gearbox) (gearbox) |
266
313 358 440 545 |
6P-315
6P-400 4P-450 4P-500 4P-630 |
33 | 14460
16260 18420 20700 22800 |
241
271 307 345 380 |
| 2BE1-705 | 210
236 266 298 330 |
(gearbox)
(gearbox) (gearbox) (gearbox) (gearbox) |
385
335 405 490 590 |
6P-400
6P-450 4P-500 4P-630 4P-710 |
160 | 17500
19700 21700 23800 26000 |
291.7
328.3 361.7 396.7 433.3 |
